RAPA - Refrigeration devices manufacturer

Can be linked in lines

Conveniently arrange the sales space in your shop with the option of linking Compact multideck refrigerated displays into refrigerated lines.

Simple design and ergonomic interior

The multideck refrigerated display is designed to be comfortable and safe to use. The ergonomic interior is easy to fill with assortments and to keep clean.

półki z listwami cenowymi ze stali nierdzewnej w regale chłodniczym

Large display area

You will gain more space for your products because we have equipped the Compact multideck display with up to 5 deep shelves that are adjustable in height every 36 mm and can be tilted by 25 degrees.

Useful glass doors

Thanks to the practical sliding glass door, you will ensure constant temperature conditions inside the device and significantly reduce electricity consumption.

drzwi przeszklone rozsuwane w regale chłodniczym

Energy-efficient LED lighting

Highlight the qualities of the products on display with LED lighting matched to the range.

Flexible design

Easily match the device to your shop design with a range of front panel finishes. Choose a painted steel or wooden panel finish. You can also opt for a stainless steel interior and shelving.

Multiple display options

You will gain new display possibilities, because we can install crossbars with "s" or "spike" hooks in the display space for you.

Precise temperature controller

You can easily set the optimum temperature inside the device thanks to the precise electronic temperature controller.

Standard equipment

Refrigerating unit

3rd climatic class
Fan assisted cooling (dynamic)
Electronic temperature controller with display
Remote version (without internal unit)

Housing

Sliding, glazed door
Upper and lower fronts painted in RAL 7016 Anthracite grey - semi-matt
Adjustable legs
Exterior side in coated steel in RAL 7016 Anthracite grey - semi-matt
Exterior side in coated steel in RAL 7016 Anthracite grey - semi-matt
All glass panes insulated, double-sided tempered, low emissivity

Exposition

LED lighting adapted to products (meat or dairy)
Exposition interior back wall painted in RAL 7016 Anthracite grey - semi-matte
Shelf set painted with supports in RAL 7016 Anthracite grey - semi-matt

Show equipment detailsHide details

Additional equipment

Shelves

Set of stainless steel shelves painted in an individual RAL colour

Accessories

Crossbar with „spitz” type hooks

Crossbar made of acid-resistant steel.
For 125/133 cm modules / displays: 9 hooks, 1 pc per level.
For 188/196 cm modules / displays: 7 hooks, 2 pcs per level
Crossbar with „S” type hooks

Crossbar made of acid-resistant steel.
For 125/133 cm modules / displays: 9 hooks, 1 pc per level.
For 188/196 cm modules / displays: 7 hooks, 2 pcs per level
Compact price strip (note: 3 pcs. are required for 1 shelf level)

Show equipment detailsShow equipment details

Parameters	Compact SR remote
temperatures range	+1°C ÷ +7°C (3 kl.)
rated voltage	230 V~ / 50 Hz
rated power	60 W
ligting power	36 W
defrosting	automatic
evaporation of condensate	into the sewage system

model	RCh-Compact SR 196/70
length [cm]	196
depth [cm]	70
height [cm]	214,5
exposition length [cm]	187,5
exposition depth - top shelves [cm]	36
exposition depth - middle shelves [cm]	40,5
exposition depth - bottom shelves [cm]	44
exposition height [cm]	170
display area [m2]	4,5 m2

model modułu	RCh- Compact SR 188/70
length [cm]	187,5
depth [cm]	70
height [cm]	214,5
exposition length [cm]	187,5
exposition depth - top shelves [cm]	36
exposition depth - middle shelves [cm]	40,5
exposition depth - bottom shelves [cm]	44
exposition height [cm]	170
display area [m2]	4,5 m2
